DBEM10-52/200YG24K4M

PVH057R02AA10B252000001A E1AB01

PVH057R02AA10B252000001A N10001

PVH057R02AA10B2520000020 01AA01

PVH057R02AA10E2520070010 01AE01

PVH057R0NAB10A2500000020 01AB01

PVH057R0NAB10B0720000020 01AE010A

PLUG CM11/RM3/MVB15PVH057R51AA10B252000001A E1AB01

PVH074L01AA10A2500000020 010001

PVH074L01AA10B2520000010 010001

PVH074L02AA10A0700000010 01AA01

PVH074L02AA10A2500000010 010001

PVH074L02AA10A2500000010 01AB01

PVH074L02AA10B2520000010 01AA01

PVH074L02AA10B2520000010 01AE010A

PVH074L02AA10B252000001A F1AG01

PVH074L02AA10B252000AL10 01AP01

PVH074L02AA10E2520150010 01AA01

PVH074L03AA10B252000001A F10001

PVH074R01AA10A0700000010 01AB01

PVH074R01AA10A0700000010 01AC01

PVH074R01AA10A1400000020 01AF01

PVH074R01AA10A2500000010 010001

PVH074R01AA10A2500000010 01AE01

PVH074R01AA10A2500000020 01AB01

PVH074R01AA10B1620000010 01AC01

PVH074R01AA10B1620000020 01AF01

PVH074R01AA10B2520000010 010001

PVH074R01AA10B2520000010 01AB01

PVH074R01AA10B2520000010 01AE01

PVH074R01AA10B2520000020 01AB01

PVH074R01AA10D2500040010 01AE01

PVH074R01AA10D2500140010 01AA01

PVH074R01AA10E2520090010 01AE01

PVH074R01AA10E2520140010 01AE01

PVH074R01AA10H002000AW10 01AB01

PVH074R01AA10H002000AW20 01AB01

PVH074R01AA50A2500000010 01AB01

PVH074R01AA50B2520000010 01AB01

PVH074R01AA50B2520000010 01AE01

PVH074R01AA50B2520000020 01AB01

PVH074R01AA60E2520090010 01AE01

PVH074R01AB50H002000AS10 01AB01

PVH074R02AA10A2500000010 010001

PVH074R02AA10A2500000010 01AE01

PVH074R02AA10A2500000020 010001

PVH074R02AA10B1920000010 0A

PVH074R02AA10B2520000010 010001

PVH074R02AA10B2520000010 01AB01

PVH074R02AA10B2520000010 020001

PVH074R02AA10B252000001A F1AA01

PVH074R02AA10B2520000020 010001

PVH074R02AA10B252000AL10 02AP01

PVH074R03AA10A250000001A F1AB01

PVH074R03AA10A250000001A F1AE01

PVH074R03AA10B252000001A F10001

PVH074R03AA10B252000001A F1AB01

PVH074R03AA10B252000001A P1AA01

PVH074R0NAB10A0700000010 01AF01

PVH074R0NAB10A2500000020 01AE01

PVH074R13AA10A160000001A F1AC01

DBEM10-52/200YG24K4M

WMM手动阀

R900466583 4WMM6J52/F

R900467370 4WMM6H52/

R900467935 3WMM6A52/

R900467936 4WMM6E52/

R900468328 4WMM6D52/

R900468746 4WMM6E52/F/B08

R900469065 4WMM6MB52/

R900469301 4WMM6D52/F

R900469302 4WMM6J52/

R900469533 4WMM6G52/F

R900470084 4WMM6GA52/F

R900501486 4WMM10EB32/F

R900501682 4WMM10U32/

R900508975 4WMM6EB52//V

R900512905 4WMM10H32//V

R900515151 4WMM10JB32/

R900526101 4WMM10JA32/F

R900526124 4WMM10EA32/

R900528555 4WMM10JA32/

R900529106 4WMM6JB52/

R900533358 H-4WMM32J52/

R900534386 3WMM10B32/

R900534388 4WMM10P32/F

R900548479 4WMM6JA52/F/V

R900595131 4WMD10E32/F

R900595191 4WMD10D32/F

R900596484 4WMD10C32/F

Z2S单向阀

R900085134 Z2S16A3-52/V

R900328797 Z2S16-1-52/

R900328798 Z2S16A1-52/

R900328799 Z2S16B1-52/

R900346704 Z2S22A1-52/V

R900347495 Z2S6-1-62/

R900347496 Z2S6-2-62/

R900347512 Z2S6B3-62/V

R900401212 Z2S16-2-52/

R900407394 Z2S10-1-33/

R900407424 Z2S10A1-33/

R900407434 Z2S10B1-33/

R900407439 Z2S10-1-33/V

Z1S单向阀

R900334980 Z1S10T2-33/V

R900334981 Z1S10T3-33/V

R900334982 Z1S10C2-33/V

R900334984 Z1S10D2-33/V

R900334985 Z1S10D3-33/V

R900334988 Z1S10B2-33/V

R900334990 Z1S10P2-33/V

R900334991 Z1S10P3-33/V

R900334992 Z1S10E2-33/V

R900334994 Z1S10F2-33/V

R900334995 Z1S10F3-33/V

DBEM10-52/200YG24K4M

图3

4、电机启动，节流阀刚打开，阀口开度还较小时的状态

A：要注意的是，在刚开始很短的一段时间内，液压缸无杆腔内的压力还未能推动活塞杆运动时（V=0），即未有油液流动，此时为静力平衡状态。

液压缸无杆腔内的压力PL将通过负载反馈油口（见图4），等值传递到负载阀滑阀右端的弹簧腔内（帕斯卡原理，图中黄色箭头表示的是力的传递方向，并不代表油液流动方向）。此时负载阀阀芯两端受静压力作用P=PL，阀芯受到150PSI的弹簧力作用使负载阀工作在右位。导致主控制活塞缸无杆腔内的部分压力油通过泄油路接通油箱。复位活塞缸中的偏置弹簧力迫使斜盘顺时针旋转，液压泵开始向系统提供较大的流量。

B：当液压缸无杆腔内的油液压力不断上升，足以推动活塞杆向左移动时（V>0），液压泵将以较大的排量向液压缸供油。

尽管压力油也会流经节流口a，但由于该节流口很小，并不会在接通负载阀滑阀弹簧腔（泄油）的油路上造成可观的功率损失。

注意到节流阀上下两端的压力表间刚好存在着150PSI的压力差。液压油通过节流阀口后所剩余的压力（负载压力）、负载阀滑阀左端的压力（泵出口的压力）、150PSI的弹簧预紧力三者之间协同工作，使节流阀阀口前后压力差得以保持。对于不同的阀口开度，液压泵均可提供与之相适应的流量。

注意，作用在负载阀滑阀左端的178PSI压力抵抗着作用于右端的28PSI压力和150PSI弹簧力，28PSI加上150PSI刚好等于178PSI（这不是一个等式，却是一种作用机理）。
